AICA Horizontal Round Tube Designer Central Heating Radiator

Horizontal Designer Round Column Heating Radiator UK

Description

• With a strict manufacturing process, our radiators offer you a heating solution at an competitive price.
• They easily fit into your central heating system like a normal household radiator, meaning no complicated installation.
• Bottom left inlet and Bottom right outlet
• It perfectly matches the decoration style of all rooms such as kitchen, bathroom, bedroom and living room.

---

Features And Details:

• High quality triple layered finish.
• Manufactured in accordance with BS EN 442
• 1/2" inlets and outlets
• Made from 1.6mm Premium Mild Steel
• Wall to pipe center: 64mm
• Wall to surface: 106mm
• Pipe Centres: 60mm
• Unique hot water circulation structure
• Modern style horizontal Round column high quality radiator
• Wall mount or stand-up installation
• Brackets and fixings included
• Valves are not included.But can be bought separately.Click here to buy our high quality valves.
• Anthracite and Black Color Are Matte and the White Color is Gloss

---

Double Round Column Designer Radiators:

Model	Size (HxW)	Panel	Net Weight	Heat Output
				BTU	Watt
Round Tube	600x384mm	Double	9.55kg	1601	469
Round Tube	600x624mm	Double	16.25kg	2572	754
Round Tube	600x804mm	Double	20.6kg	3319	973
Round Tube	600x1104mm	Double	28.2kg	4574	1341
Round Tube	600x1284mm	Double	33.9kg	5338	1564
Round Tube	600x1404mm	Double	37.05kg	5912	1733
Round Tube	600x1584mm	Double	41.7kg	6587	1930
Round Tube	1600x264mm	Double	16.25kg	2675	784
Round Tube	1600x384mm	Double	24.2kg	4117	1207
Round Tube	1600x504mm	Double	32.1kg	5553	1627
Round Tube	1600x624mm	Double	40.15kg	7010	2054
Round Tube	1800x264mm	Double	18.2kg	3187	934
Round Tube	1800x384mm	Double	27.25kg	4629	1357
Round Tube	1800x504mm	Double	35.8kg	6065	1777
Round Tube	1800x624mm	Double	45.05kg	7522	2204



---

*Not recommend to install any pipework before you receive your radiator.

*BTU for reference only, it depends on various elements such as flow temperature and indoor temperature.
